<blockquote>
The Domain layer defines what exists. The Application layer defines what’s possible. The Infrastructure layer makes it actually work.
</blockquote>
<hr>
<h2>Day 5 of building SGAcademy in public</h2>
Yesterday I built the Application layer — services, DTOs, AutoMapper profiles. All clean. All abstract. No database anywhere in sight.
Today that changes.
The Infrastructure layer is where the contracts finally get implemented. <code>IStudentRepository</code> gets a real class. <code>DbContext</code> gets configured. Entity Framework Core starts talking to SQL Server.
This is where clean architecture earns its cost.
<hr>
<h2>What lives in the Infrastructure layer</h2>
Four things:
<ul>
<li>EF Core DbContext — the single entry point to the database</li>
<li>Repository implementations — concrete classes that implement domain contracts</li>
<li>EF Configurations — <code>IEntityTypeConfiguration&lt;T&gt;</code> files that map entities to tables</li>
<li>Interceptors — <code>SaveChangesInterceptor</code> hooks that auto-stamp audit and academic year fields</li>
</ul>
The Infrastructure layer depends on the Domain layer. It knows about Entity Framework. The Application layer does not.
<hr>
<h2>The DbContext</h2>
One <code>DbContext</code> for the whole system. It extends <code>IdentityDbContext</code> to plug in <a href="http://ASP.NET" target="_blank" rel="noopener nofollow">ASP.NET</a> Identity, registers all <code>DbSet</code>s, and wires in both interceptors.
<pre><code class="language-csharp">public class ApplicationDbContext : IdentityDbContext&lt;ApplicationUser, ApplicationRole, Guid&gt;
{
 public DbSet&lt;Student&gt; Students =&gt; Set&lt;Student&gt;();
 public DbSet&lt;Staff&gt; Staff =&gt; Set&lt;Staff&gt;();
 // ... all entities

 protected override void OnModelCreating(ModelBuilder builder)
 {
 base.OnModelCreating(builder);
 builder.ApplyConfigurationsFromAssembly(Assembly.GetExecutingAssembly());
 }
}
</code></pre>
<code>ApplyConfigurationsFromAssembly</code> picks up every <code>IEntityTypeConfiguration&lt;T&gt;</code> automatically. No manual registration needed.
<hr>
<h2>EF Configurations: one file per entity</h2>
No fluent API in <code>OnModelCreating</code> — that becomes unmanageable fast. Every entity gets its own configuration file.
<pre><code class="language-csharp">public class StudentConfiguration : IEntityTypeConfiguration&lt;Student&gt;
{
 public void Configure(EntityTypeBuilder&lt;Student&gt; builder)
 {
 builder.Property(s =&gt; s.FullName).IsRequired().HasMaxLength(150);
 builder.Property(s =&gt; s.RegistrationNumber).IsRequired().HasMaxLength(20);
 builder.HasIndex(s =&gt; s.RegistrationNumber).IsUnique();
 builder.HasMany(s =&gt; s.Enrollments)
 .WithOne(e =&gt; e.Student)
 .OnDelete(DeleteBehavior.Restrict);
 }
}
</code></pre>
One file. One entity. Scales cleanly as the schema grows.
<hr>
<h2>The Repository pattern</h2>
Every entity has an interface in Domain and a concrete implementation in Infrastructure.
<code>RepositoryBase&lt;T&gt;</code> handles shared CRUD so you never repeat it:
<pre><code class="language-csharp">public abstract class RepositoryBase&lt;T&gt; : IRepositoryBase&lt;T&gt; where T : class
{
 protected ApplicationDbContext Context;

 public IQueryable&lt;T&gt; FindByCondition(Expression&lt;Func&lt;T, bool&gt;&gt; expr, bool trackChanges) =&gt;
 trackChanges ? Context.Set&lt;T&gt;().Where(expr)
 : Context.Set&lt;T&gt;().Where(expr).AsNoTracking();

 public void Create(T entity) =&gt; Context.Set&lt;T&gt;().Add(entity);
 public void Delete(T entity) =&gt; Context.Set&lt;T&gt;().Remove(entity);
}
</code></pre>
Concrete repositories extend the base and only add specialised queries:
<pre><code class="language-csharp">public class StudentRepository : RepositoryBase&lt;Student&gt;, IStudentRepository
{
 public async Task&lt;Student?&gt; GetByIdAsync(Guid id, bool trackChanges) =&gt;
 await FindByCondition(s =&gt; s.Id == id, trackChanges).FirstOrDefaultAsync();
}
</code></pre>
<hr>
<h2>IRepositoryWrapper: one dependency to rule them all</h2>
Instead of injecting five repositories into every service, SGAcademy uses a wrapper:
<pre><code class="language-csharp">public class RepositoryWrapper : IRepositoryWrapper
{
 private IStudentRepository? _student;
 public IStudentRepository Student =&gt; _student ??= new StudentRepository(_context);

 // ... same pattern for Staff, Class, Enrollment, Attendance

 public async Task SaveAsync() =&gt; await _context.SaveChangesAsync();
}
</code></pre>
One <code>SaveAsync()</code> call. One unit of work. Services don’t care how many repositories they touched — they just call <code>SaveAsync()</code> at the end.
<hr>
<h2>Interceptors: automatic stamping</h2>
Two interceptors run on every <code>SaveChanges</code>. You never call them manually — EF triggers them automatically.
AuditableEntitySaveChangesInterceptor stamps <code>CreatedAt</code>, <code>UpdatedAt</code>, <code>CreatedBy</code>, <code>UpdatedBy</code> on every entity that extends <code>AuditableEntity</code>:
<pre><code class="language-csharp">public class AuditableEntitySaveChangesInterceptor : SaveChangesInterceptor
{
 private readonly ICurrentUserService _currentUser;

 public AuditableEntitySaveChangesInterceptor(ICurrentUserService currentUser)
 =&gt; _currentUser = currentUser;

 public override InterceptionResult&lt;int&gt; SavingChanges(
 DbContextEventData eventData, InterceptionResult&lt;int&gt; result)
 {
 UpdateAuditFields(eventData.Context);
 return base.SavingChanges(eventData, result);
 }

 private void UpdateAuditFields(DbContext? context)
 {
 if (context is null) return;

 foreach (var entry in context.ChangeTracker.Entries&lt;AuditableEntity&gt;())
 {
 if (entry.State == EntityState.Added)
 {
 entry.Entity.CreatedAt = DateTime.UtcNow;
 entry.Entity.CreatedBy = _currentUser.UserId;
 }
 if (entry.State is EntityState.Added or EntityState.Modified)
 {
 entry.Entity.UpdatedAt = DateTime.UtcNow;
 entry.Entity.UpdatedBy = _currentUser.UserId;
 }
 }
 }
}
</code></pre>
AcademicYearSaveChangesInterceptor stamps <code>AcademicYearId</code> on every entity that implements <code>IAcademicYearEntity</code>:
<pre><code class="language-csharp">public class AcademicYearSaveChangesInterceptor : SaveChangesInterceptor
{
 private readonly ICurrentAcademicYearService _academicYear;

 public AcademicYearSaveChangesInterceptor(ICurrentAcademicYearService academicYear)
 =&gt; _academicYear = academicYear;

 public override InterceptionResult&lt;int&gt; SavingChanges(
 DbContextEventData eventData, InterceptionResult&lt;int&gt; result)
 {
 if (eventData.Context is null) return base.SavingChanges(eventData, result);

 foreach (var entry in eventData.Context.ChangeTracker.Entries&lt;IAcademicYearEntity&gt;())
 {
 if (entry.State == EntityState.Added)
 entry.Entity.AcademicYearId = _academicYear.CurrentId;
 }

 return base.SavingChanges(eventData, result);
 }
}
</code></pre>
Add the base class or interface to your entity. Get the stamping for free. No extra code anywhere else.
<hr>
<h2>Registering everything</h2>
One extension method in <code>ServiceExtensions.cs</code>, called once from <code>Program.cs</code>:
<pre><code class="language-csharp">services.AddDbContext&lt;ApplicationDbContext&gt;(options =&gt;
 options.UseSqlServer(config.GetConnectionString(&quot;DefaultConnection&quot;)));

services.AddScoped&lt;IRepositoryWrapper, RepositoryWrapper&gt;();
services.AddScoped&lt;AuditableEntitySaveChangesInterceptor&gt;();
services.AddScoped&lt;AcademicYearSaveChangesInterceptor&gt;();
</code></pre>
Done.
<hr>
<h2>The mistake I see everywhere</h2>
Putting EF queries directly in services.
<pre><code class="language-csharp">// Wrong — your service now knows about DbContext
var students = await _context.Students
 .Where(s =&gt; s.Status == StudentStatus.Active)
 .ToListAsync();
</code></pre>
Now your Application layer has an EF dependency. You can’t swap the database without touching business logic.
Put it in the repository. The service stays clean. Infrastructure stays contained.
<hr>
<h2>What I shipped today</h2>
<ul>
<li><code>ApplicationDbContext</code> with Identity integration and interceptor wiring</li>
<li>EF configurations for all five core entities</li>
<li><code>RepositoryBase&lt;T&gt;</code> with generic CRUD + no-tracking support</li>
<li>Concrete repositories for Student, Staff, Class, Enrollment, Attendance</li>
<li><code>RepositoryWrapper</code> as the unit of work</li>
<li>Both <code>SaveChanges</code> interceptors auto-stamping audit and academic year fields</li>
<li>Everything wired into DI via <code>ServiceExtensions</code></li>
</ul>
First migration created. Database schema generated. SQL Server has tables.
The backend now has all four layers: Domain → Application → Infrastructure → API (next).
<hr>
<h2>One principle to take away</h2>
The Infrastructure layer’s only job is to implement contracts the domain defined.
Business logic in a repository? Wrong layer. EF queries in a service? Wrong layer.
Every layer has one job. Let it do exactly that job.
<hr>
<h2>Tomorrow</h2>
Day 6: The API layer — controllers, middleware, global exception handling, and how the whole stack finally connects end to end.
<hr>
Learn | Build | Ship — BuildWithRafique <code>&lt;R/&gt;</code>
